This product is no longer available.
iiyama T2234MC-B1X Capacitive T 10P
Item code
T2234MC-B1X
EAN-code
4948570113187
Solutions
Interactive / Touch
Display diagonal
22 "
Downloads
Click here for the downloads
Are you interested in purchasing this product?
Related products
Highlighted functionality
Specifications
Touch technology - capacitive
This technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (gloved or not) and magnetic ball.
IPS
IPS panel technology technology offers higher contrast, darker blacks and much better viewing angles than standard TN technology. The screen will look good no matter what angle you look at it.
Multi-touch
The multi-touch functionality is supported under Windows® 7/8 only.
IP54
The IP Code classifies how resistant a device is to foreign objects and moisture. IP54 means that the monitor will operate in dusty conditions, and will resist splashing water.
This technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (gloved or not) and magnetic ball.
IPS
IPS panel technology technology offers higher contrast, darker blacks and much better viewing angles than standard TN technology. The screen will look good no matter what angle you look at it.
Multi-touch
The multi-touch functionality is supported under Windows® 7/8 only.
IP54
The IP Code classifies how resistant a device is to foreign objects and moisture. IP54 means that the monitor will operate in dusty conditions, and will resist splashing water.
Display
Display diagonal
22 "
Display technology
LED
LED backlight
Yes
Display resolution
1920 x 1080 pixels
Display brightness
225 cd/m²
HD type
Full HD
Response time
8.00 ms
Contrast ratio (typical)
1000:1
Viewing angle, horizontal
178.00 °
Viewing angle, vertical
178.00 °
Display number of colours
16.78 million colours
Screen shape
Flat
Pixel pitch
0.247 x 0.247 mm
Display diagonal (metric)
55.00 cm
Touchscreen technology
Capacitive
Supported graphics resolutions
640 x 480 (VGA),800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1440 x 900 (WXGA+),1680 x 1050 (WSXGA+),1920 x 1080 (HD 1080)
Native aspect ratio
16:9
Touchscreen type
Tabletop
Touchscreen
Yes
Touch technology
Multi-touch
Aspect ratio
16:9
Ports & interfaces
Number of upstream ports
1
VGA (D-Sub) ports quantity
1
DVI-D ports quantity
1
USB 2.0 ports quantity
1.00
Total number of outputs
1
DVI ports
1
VGA ports
1
Weight & dimensions
Width (without stand)
517.50 cm
Width
517.50 mm
Depth
46.00 mm
Height
313.50 mm
Weight
5000.00 g
Width (with stand)
517.50 mm
Depth (with stand)
219.00 mm
Height (with stand)
351.70 mm
Depth (without stand)
46.00 cm
Height (without stand)
313.50 cm
Weight with stand
7200.00 g
Package width
615 mm
Package depth
330 mm
Package height
450 mm
Package weight
9900 g
Power
Power consumption (typical)
27.00 W
Power consumption (max)
30.00 W
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Energy efficiency class
B
Power consumption (PowerSave)
2.00 W
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
20 - 80 %
Storage temperature (T-T)
-20 - 60 °C
Storage relative humidity (H-H)
10 - 90 %
Certificates
RoHS compliance
Yes
Certification
CE, TÃœV-Bauart, VCCI-B
Management features
On Screen Display (OSD)
Yes
Number of OSD languages
8.00
Ergonomics
Wall mountable
Yes
VESA mounting
Yes
Panel mounting interface
100 x 100 mm
On Screen Display (OSD) languages
CHI (SIMPL),CHI (TR),DEU,ENG,ESP,FRE,ITA,JPN
Pivot
Yes
Tilt adjustment
Yes
Cable lock slot
Yes
Tilt angle range
-5 - 90 °
Plug and Play
Yes
Packaging content
Cables included
AC,DVI,USB,VGA
Quick start guide
Yes
Other features
DVI port
Yes
Display viewable area (HxV)
476.6 x 268.1 mm
Dimensions (W x D x H) with stand
517.5 x 219 x 351.7 mm
Design
Display type
LED
Product colour
Black
International Protection (IP) code
IP54
Display
IPS
Performance
NVIDIA G-SYNC
No
AMD FreeSync
No
Number of simultaneous touchpoints (Windows 7)
10.00
Horizontal scan range
31.5 - 82.3 kHz
Vertical scan range
56 - 75 Hz
Separate H/V sync
Yes
Recommended usage
18 / 7
Video
Full HD
Yes
Software
Windows operating systems supported
Y
Multimedia
Built-in camera
No
Energy efficiency class (SDR)
F
Weight (with stand)
7200 kg
Sustainability certificates
RoHS
Tiltable
Y
Weight (without stand)
5000.00 kg
Harmonized System (HS) code
85285210
Energy efficiency class (old)
B
