Samsung WM55R 55" Flip2.0
Item code
LH55WMRWBGCXEN
EAN-code
8801643914288
Solutions
Interactive / Touch
Display diagonal
55 "
Downloads
Click here for the downloads
Are you interested in purchasing this product?
Related products
Highlighted functionality
Specifications
Draw, write & inspire new ideas
Pen mode notation
Samsung Flip provides users with a smooth and familiar pen to paper writing experience in a variety of available colours, styles and widths. Up to 4 people can write simultaneously, using any object as a writing tool. In addition, users can quickly erase the drawings with a finger or palm swipe.
Pen mode notation
Samsung Flip provides users with a smooth and familiar pen to paper writing experience in a variety of available colours, styles and widths. Up to 4 people can write simultaneously, using any object as a writing tool. In addition, users can quickly erase the drawings with a finger or palm swipe.
Technical details
Orientation
Horizontal/Vertical
Display
Display diagonal
55 "
Display technology
LED
Display resolution
3840 x 2160 pixels
Display brightness
350 cd/m²
HD type
4K Ultra HD
Response time
8.00 ms
Contrast ratio (typical)
4000:1
Viewing angle, horizontal
178.00 °
Viewing angle, vertical
178.00 °
Pixel pitch
0.315 x 0.315 mm
Touchscreen
Yes
Audio
Built-in speaker(s)
Yes
Ports & interfaces
HDMI ports quantity
2
Ethernet LAN (RJ-45) ports
1.00
RS-232 interface
Yes
USB port
Yes
USB ports quantity
1.00
Total number of outputs
2
HDMI ports
2
RS-232 (C)
Yes
Weight & dimensions
Width
835.00 mm
Depth
1631.10 mm
Height
1632.90 mm
Weight
34500.00 g
Depth (max)
850.60 cm
Package width
1650 mm
Package depth
208 mm
Package height
860 mm
Package weight
41500 g
Power
Power consumption (typical)
154.00 W
Power consumption (standby)
0.50 W
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 80 %
Network
Ethernet LAN
Yes
Ergonomics
VESA mounting
Yes
Panel mounting interface
400 x 400 mm
Angle of rotation
90.00 °
Number of wheels
4.00
Packaging content
Remote control included
Yes
Cables included
AC
Mounting kit
Yes
Manual
Yes
Quick start guide
Yes
Stylus pen
Yes
Other features
Wi-Fi
Yes
Wheels
Y
Placement supported
Indoor
Design
Product design
Digital signage flat panel
Display type
LED
Product colour
Grey
Performance
Operating hours (hours/days)
16/7
Horizontal scan range
30 - 81 kHz
Vertical scan range
48 - 75 Hz
Mounting
Maximum screen size
55.00 mm
Number of displays supported
1.00
Minimum VESA mount
400 x 400 mm
Maximum VESA mount
400 x 400 mm
Mounting type
Floor
Keyboard
Purpose
Universal
Harmonized System (HS) code
85299097
Packaging content
Screws
