This product is no longer available. One of the successors is Samsung QM75R UHD

Samsung QM75N UHD

Item code LH75QMNEBGC/EN
EAN-code 8801643307158
Solutions Digital Signage
Display diagonal 75 "

Are you interested in purchasing this product?

Highlighted functionality
Specifications
Deliver Clear Messaging that Resonates
Whether for a retailer promoting new sales or a transportation hub keeping travelers on schedule, clear information delivery drives success. Samsung’s QMN Series help businesses achieve these goals through compelling UHD picture quality, extensive connectivity and ongoing 24/7 performance.

Share Intelligent, High-Quality Content
Intelligent Picture Quality
The QMN Series displays leverage Samsung’s Intelligent Picture Quality technology to elevate content delivery in any setting. This refined presentation transforms content from any source to UHD-level quality, and optimizes on-screen text and imagery with crisp edges and fine detail.

Streamline Operational Efficiency
The embedded MagicINFO Player S6, backed by the powerful TIZEN operating system, boosts the displays overall performance, allows for painless content management and ensures seamless content transition and playback.

Empower Secure and Remote Collaboration
Samsung’s KNOX platform provides rigid three-layer protection while also securing and controlling USB and user network exchange through dedicated signage device management. With added security, businesses can facilitate remote, PC-free meetings without risk or complexity.

Maintain Continuous Display Performance
Beyond security and content management, QMN Series users can trust the displays’ remote management for fast, efficient issue mitigation. Users can monitor and diagnose irregularities – both on their own and with help from Samsung’s 24/7 Network Operations Center – from any location.

Enjoy Convenient Display Management
The QMN Series’ integrated centralized infrared receiver (IR) ensures easier and more flexible user control. Each display receives signals on individual panels via Central IR, and users can navigate the IR functionality from various locations to further augment uninterrupted performance.

Shield Content From Outside Interference
The QMN Series’ durable, IP5x-validated design ensures continuous, glare-free content delivery regardless of environmental conditions. As a result, transportation hubs and other arenas susceptible to dust, dirt and lighting exposure can activate and run the displays without an external enclosure.

Accelerate Multi-Screen Content Delivery
For added flexibility, the QMN Series offers users HDMI 2.0 and DP 1.2 port connectivity. This versatility ensures a consistent 60 Hz. refresh rate and optimal clarity regardless of the source. Additionally, users can configure UHD daisy chains up to 2x2 in size through the HDMI 2.0 port.

Technical details

Sustainability certificates
ENERGY STAR

Display

Display diagonal
75 "
Display resolution
3840 x 2160 pixels
Display brightness
500 cd/m²
HD type
4K Ultra HD
Response time
8.00 ms
Contrast ratio (typical)
6000:1
Dynamic contrast ratio marketing name
Mega Contrast
Viewing angle, horizontal
178.00 °
Viewing angle, vertical
178.00 °
Display number of colours
16.78 million colours
Pixel pitch
0.42975 x 0.42975 mm
Active display area (W x H)
1650.24 x 928.26 mm
Horizontal scan range
30 - 81 kHz
Vertical scan range
48 - 75 Hz
Supported graphics resolutions
3840 x 2160
Colour gamut
72.00 %

Audio

Number of built-in speakers
2.00
Built-in speaker(s)
Yes

Ports & interfaces

Ethernet LAN
Yes
HDMI ports quantity
3
HDMI input ports quantity
2
Wi-Fi
Yes
HDMI version
2.0
DVI port
Yes
DVI-D ports quantity
1
HDMI in
2
Ethernet LAN (RJ-45) ports
1.00
USB port
Yes
USB ports quantity
2.00
USB version
2.0
PC Audio in
Yes
RS-232C
Yes
Remote (IR) input
1.00
DisplayPorts quantity
1
Total number of outputs
5
HDMI ports
3
DVI ports
1
Displayport ports
1
RS-232 (C)
Yes

Weight & dimensions

Width
1684.60 mm
Depth
60.40 mm
Height
966.70 mm
Weight
38000.00 g

Power

Power consumption (typical)
159.00 W
AC input voltage
100-240 V
AC input frequency
50 - 60 Hz
Energy efficiency class
A
Energy Star certified
Yes

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 80 %

Other features

Energy efficiency class (old)
A

Design

Product colour
Black
VESA mounting
Yes
Panel mounting interface
400 x 400 mm
Bezel width (bottom)
17.70 cm
Bezel width (side)
13.50 cm
Bezel width (top)
13.50 cm

Performance

Purpose
Universal
Operating hours (hours/days)
24/7
HDCP
Yes
International Protection (IP) code
IP5X

Packaging data

Package width
1871 mm
Package depth
234 mm
Package height
1131 mm
Package weight
50500 g
