This product is no longer available.
One of the successors is Samsung QM65N UHD
Samsung QM65H
Item code
LH65QMHPLGC/EN
EAN-code
8806088858777
Solutions
Digital Signage
Display diagonal
65 "
Downloads
Click here for the downloads
Are you interested in purchasing this product?
Related products
Highlighted functionality
Specifications
There is no description available at this time.
Technical details
DisplayPorts in
1.00
Full HD
Yes
RJ-45 input ports
1.00
DVI input ports
1.00
DisplayPort version
1.2
LED backlighting type
Edge-LED BLU
24-hour use
Y
HDCP 2.2
Y
Display
Display diagonal
65 "
Display technology
LED
Display type
LED
Display resolution
3840 x 2160 pixels
Display brightness
500 cd/m²
HD type
4K Ultra HD
Response time
8.00 ms
Contrast ratio (typical)
4000:1
Dynamic contrast ratio marketing name
Mega Contrast
Viewing angle, horizontal
178.00 °
Viewing angle, vertical
178.00 °
Display number of colours
16.78 million colours
Pixel pitch
0.105 x 0.315 mm
Active display area (W x H)
814.52 x 1438.48 mm
Display diagonal (metric)
163.00 cm
Native aspect ratio
16:9
Colour depth
10.00 bit
Native refresh rate
60 Hz
Haze rate
25 %
Horizontal scan range
30 - 81 kHz
Vertical scan range
48 - 75 Hz
Colour gamut
72.00 %
Touchscreen
No
Audio
Number of built-in speakers
2.00
Built-in speaker(s)
Yes
RMS rated power
20.00 W
Ports & interfaces
Ethernet LAN
Yes
HDMI ports quantity
3
HDMI input ports quantity
2
Wi-Fi
Yes
HDMI version
2.0
DVI port
Yes
DVI-D ports quantity
1
HDMI in
2
Audio (L/R) in
1.00
Audio (L/R) out
1.00
Ethernet LAN (RJ-45) ports
1.00
RS-232 interface
Yes
USB port
Yes
Remote (IR) input
1.00
USB ports quantity
2.00
USB version
2.0
DisplayPorts quantity
1
RS-232 (C)
Yes
Total number of outputs
5
HDMI ports
3
DVI ports
2
Displayport ports
1
Weight & dimensions
Width
1456.10 mm
Depth
37.50 mm
Height
835.60 mm
Weight
22800.00 g
Power
Power consumption (typical)
198.00 W
Power consumption (standby)
0.50 W
Energy efficiency scale
A+++ to D
Annual energy consumption
183.00 kWh
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power consumption (sleep)
0.50 W
Power consumption (off)
0.50 W
Energy efficiency class
A
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 80 %
Storage temperature (T-T)
-20 - 45 °C
Storage relative humidity (H-H)
5 - 95 %
Other features
System on Chip (SoC) type
Samsung SMART Signage Platform (SSSP) Gen 5
SMART Signage TV (SSTV)
Y
Safety
CB (Europe): IEC60950-1 / EN60950-1CCC (China): GB4943.1-2011PSB (Singapore): PSB + IEC60950-1NOM (Mexico): NOM-001-SCFI-1993IRAM (Argentina): IRAM + IEC60950-1SASO (Saudi Arabia): IAS60950-1 / IS13252NOM (Mexico): Tuner: NOM-001-SCFI-1993 Tunerless: NOM-019-SCFI-1998KC (Korea): K 60950-1EAC ( Russia): EAC + IEC60950-1INMETRO (Brazil): INMETRO + IEC60950-1BSMI (Taiwan): IBC60950-1 / AS / NZS 60950-1UL ): CULTUV (Germany): CENEMKO (Norway): CE
Pivot
Y
Power cord included
Yes
RJ-45 ports quantity
1.00
USB 2.0 ports quantity
2.00
Bluetooth
Yes
Plug and Play
Yes
Energy efficiency class (old)
A
Design
Product design
Digital signage flat panel
Product colour
Black
VESA mounting
Yes
Panel mounting interface
400 x 400 mm
Bezel width (bottom)
12.00 cm
Bezel width (side)
12.00 cm
Bezel width (top)
12.00 cm
Certification
FCC (USA) Part 15, Subpart B Class ACE (Europe) : EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003VCCI (Japan) : VCCI V-3 /2010.04 Class AKCC/EK (Korea) : Tuner : KN13 / KN20 Tunerless : KN22 / KN24BSMI (Taiwan) : CNS13438 (ITE EMI) Class A / CNS13439 (AV EMI) / CNS14409 (AV EMS) / CNS14972 (Digital)C-Tick (Australia) : AS/NZS CISPR22:2009CCC(China) :GB9254-2008 GB17625.1-2012GOST(Russia/CIS) : GOST R 51317 Series, GOST 22505-97 EN55022:2006+A1:2007 EN55024:1998+A1:2001+A2:2003
Performance
Purpose
Commercial
Operating hours (hours/days)
24/7
HDCP
Yes
Media player option type
Set Back Box (SBB)
International Protection (IP) code
IPX5
HDCP version
2.2
Packaging data
Remote control included
Yes
Batteries included
Yes
Cables included
AC
Quick start guide
Yes
Warranty card
Yes
Package width
1571 mm
Package depth
212 mm
Package height
956 mm
Package weight
30300 g
Computer system
Computer system
Yes
Computer system type
System on Chip (SoC)
Built-in processor
Y
Processor family
ARM Cortex
Processor model
A72
Processor frequency
1.70 GHz
Processor cores
4
Operating system installed
Tizen 3.0
Internal memory
3.00 GB
Internal storage capacity
8.00 GB
Video formats supported
AVC,AVS,H.263,H.264,HEVC,MPEG1,MPEG2,MPEG4,MVC,VC-1,VP8,VP9
Audio formats supported
AC3,MP3
Image formats supported
JPEG,PNG
Harmonized System (HS) code
85285210
