This product is no longer available.
Samsung DC43J
Item code
LH43DCJPLGC/EN
EAN-code
8801643024727
Solutions
Digital Signage
Display diagonal
43 "
Downloads
Click here for the downloads
Are you interested in purchasing this product?
Related products
Highlighted functionality
Specifications
Amplify Business Messaging
The DCJ series combines FHD resolution, 300nit brightness, and 16/7 reliability to boost engagement and relay timely information with superior content presentation.
Load and Share with Ease
The embedded MagicInfo Lite Player allows users to conveniently load and play a wide range of content types. Simply plug in a USB device to the built-in port or access the internal memory to display the desired content on the screen.
Simplify Content Scheduling
Utilize the Local Schedule Manager to seamlessly play content from the internal memory and/or a USB drive. For added convenience, configure playback settings and create schedules directly through the display with a remote control.
Diversify Connectivity Preferences
With a versatile interface including USB, DVI, HDMI, RS-232C and RJ45, easily connect and use a wide array of devices with the display.
The DCJ series combines FHD resolution, 300nit brightness, and 16/7 reliability to boost engagement and relay timely information with superior content presentation.
Load and Share with Ease
The embedded MagicInfo Lite Player allows users to conveniently load and play a wide range of content types. Simply plug in a USB device to the built-in port or access the internal memory to display the desired content on the screen.
Simplify Content Scheduling
Utilize the Local Schedule Manager to seamlessly play content from the internal memory and/or a USB drive. For added convenience, configure playback settings and create schedules directly through the display with a remote control.
Diversify Connectivity Preferences
With a versatile interface including USB, DVI, HDMI, RS-232C and RJ45, easily connect and use a wide array of devices with the display.
Technical details
LED backlighting type
Direct-LED BLU
Display
Display diagonal
43 "
Display technology
LED
Display type
LED
Display resolution
1920 x 1080 pixels
Display brightness
300 cd/m²
HD type
Full HD
Response time
8.00 ms
Contrast ratio (typical)
3000:1
Dynamic contrast ratio marketing name
Mega Contrast
Viewing angle, horizontal
178.00 °
Viewing angle, vertical
178.00 °
Display number of colours
16.78 million colours
Pixel pitch
0.16333 x 0.49005 mm
Active display area (W x H)
940.89 x 529.25 mm
Display diagonal (metric)
108.00 cm
Colour saturation
72 %
Horizontal scan range
30 - 81 kHz
Vertical scan range
48 - 75 Hz
Colour gamut
72.00 %
Haze rate
2 %
Touchscreen
No
Audio
Number of built-in speakers
2.00
Built-in speaker(s)
Yes
RMS rated power
20.00 W
Ports & interfaces
Ethernet LAN
Yes
HDMI ports quantity
2
Wi-Fi
No
HDMI version
1.4
DVI port
Yes
DVI-I ports quantity
1
Component video (YPbPr/YCbCr) in
1
Audio (L/R) in
1.00
Audio (L/R) out
1.00
Ethernet LAN (RJ-45) ports
1.00
RS-232 interface
Yes
USB port
Yes
USB ports quantity
1.00
USB version
2.0
PC Audio in
Yes
RS-232C
Yes
Remote (IR) output
1.00
Total number of outputs
3
HDMI ports
2
DVI ports
1
RS-232 (C)
Yes
Weight & dimensions
Width
985.50 mm
Depth
73.40 mm
Height
574.80 mm
Weight
7800.00 g
Power
Power consumption (typical)
53.00 W
Power consumption (standby)
0.50 W
Energy efficiency class (SDR)
G
Energy efficiency scale
A to G
Energy consumption (SDR) per 1000 hours
58 kWh
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power consumption (sleep)
0.50 W
Heat dissipation
337.00 BTU/h
Energy efficiency class
A
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
10 - 80 %
Other features
L2 cache
128.00 KB
Plug and Play
Y
Energy efficiency class (old)
A
Design
Product design
Digital signage flat panel
Product colour
Black
VESA mounting
Yes
Panel mounting interface
200 x 200 mm
Bezel width (bottom)
18.30 cm
Bezel width (side)
21.30 cm
Bezel width (top)
17.30 cm
Placement supported
Indoor
Performance
Purpose
Universal
Operating hours (hours/days)
16/7
HDCP
Yes
Packaging data
Remote control included
Yes
Batteries included
Yes
Cables included
AC
Quick start guide
Yes
Package width
1099 mm
Package depth
156 mm
Package height
672 mm
Package weight
11500 g
Computer system
Computer system
Yes
Processor family
MIPS
Processor model
24K
Operating system installed
Samsung Proprietary OS
Harmonized System (HS) code
85285210
