Newstar FPMA-D1020
Item code
FPMA-D1020
EAN-code
8717371441760
Downloads
Click here for the downloads
Are you interested in purchasing this product?
Related products
Highlighted functionality
Specifications
The Neomounts desk mount, model FPMA-D1020 is a tilt-, swivel and rotatable desk mount for flat screens up to 30". This mount is a great choice for space saving placement on desks using a desk clamp.
Neomounts's versatile tilt (180°), rotate (180°) and swivel (260°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The mount is manually height adjustable from 0 to 40 centimetres. Depth adjustable from 16 to 36 centimetres. An innovative cable management conceals and routes cables from mount to flat screen. Hide your cables to keep the workplace nice and tidy.
Neomounts FPMA-D1020 has two pivot points and is suitable for screens up to 30" (76 cm). The weight capacity of this product is 10 kg each screen. The desk mount is suitable for screens that meet VESA hole pattern 75x75 or 100x100mm. Different hole patterns can be covered using Neomounts VESA adapter plates.
By using an ergonomic mount neck- and back complaints can be avoided. Ideal for use in offices and on counters or in a reception area.
All installation material is included with the product.
Neomounts's versatile tilt (180°), rotate (180°) and swivel (260°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The mount is manually height adjustable from 0 to 40 centimetres. Depth adjustable from 16 to 36 centimetres. An innovative cable management conceals and routes cables from mount to flat screen. Hide your cables to keep the workplace nice and tidy.
Neomounts FPMA-D1020 has two pivot points and is suitable for screens up to 30" (76 cm). The weight capacity of this product is 10 kg each screen. The desk mount is suitable for screens that meet VESA hole pattern 75x75 or 100x100mm. Different hole patterns can be covered using Neomounts VESA adapter plates.
By using an ergonomic mount neck- and back complaints can be avoided. Ideal for use in offices and on counters or in a reception area.
All installation material is included with the product.
Weight & dimensions
Height
400.00 mm
Package width
170 mm
Package depth
210 mm
Package height
450 mm
Ergonomics
Angle of rotation
180.00 °
Distance to the wall (min)
160.00 mm
Distance to the wall (max)
360.00 mm
Height adjustment
Y
Height adjustment range
0 - 400 mm
Swivel angle
260.00 °
Tilt angle range
0 - 180 °
Other features
Country of origin
Taiwan
Mounting interface
VESA 75 x 75mm, 100 x 100mm
Design
Product colour
Silver
Mounting
Minimum screen size
10.00 mm
Maximum screen size
30.00 mm
Mounting
Clamp
Maximum weight capacity
10.00 kg
Number of displays supported
1.00
Minimum VESA mount
75 x 75 mm
Maximum VESA mount
100 x 100 mm
Mounting type
Desk
Master (outer) case width
470.00 cm
Master (outer) case length
430 cm
Master (outer) case height
190.00 cm
Products per master (outer) case
2 pc(s)
Height adjustment type
Manual
Depth adjustment range
160 - 360 mm
Master (outer) case net weight
8480 kg
Harmonized System (HS) code
85299097
Products per pallet (EU)
84.00 pc(s)
