This product is no longer available.
NEC MultiSync E233WMi white
Item code
60004377
EAN-code
5028695114425
Solutions
Office Monitors
Display diagonal
23 "
Downloads
Click here for the downloads
Are you interested in purchasing this product?
Related products
Highlighted functionality
Specifications
NEC MultiSync ® E233WMi – maximum flexibility for a healthy performance
The 23” 16:9 wide screen display targeting entry-level office applications.
With its IPS panel providing wide viewing angles, the screen features an easy-to-read and eye-pleasing image quality, whilst providing best performance for better working results.
Highly flexible ergonomic setting options including height adjust, tilt and swivel as well as vertical and horizontal display orientation results in a more pleasant and productive working environment. Ensuring the well-being of the user, built-in Low Blue Light Plus technology filters out hazardous blue light emissions whilst Flicker-Free technology eliminates the effect of flickering. Whilst the users’ eyes are protected, the low power consumption ensures an attractive Total Cost of Ownership.
- Ergonomic Office – full height adjustability (110 mm), swivel, tilt and pivot functionality ensures perfect individual ergonomic set-up.
- Ecologics and Ergonomics – complying to the latest standards including TCO 6.0 and ISO 6-0.
- Cost Saving Device Management – save effort whilst managing all connected NEC devices from a centralised location by using the NaViSet Administrator 2 software tool.
The 23” 16:9 wide screen display targeting entry-level office applications.
With its IPS panel providing wide viewing angles, the screen features an easy-to-read and eye-pleasing image quality, whilst providing best performance for better working results.
Highly flexible ergonomic setting options including height adjust, tilt and swivel as well as vertical and horizontal display orientation results in a more pleasant and productive working environment. Ensuring the well-being of the user, built-in Low Blue Light Plus technology filters out hazardous blue light emissions whilst Flicker-Free technology eliminates the effect of flickering. Whilst the users’ eyes are protected, the low power consumption ensures an attractive Total Cost of Ownership.
- Ergonomic Office – full height adjustability (110 mm), swivel, tilt and pivot functionality ensures perfect individual ergonomic set-up.
- Ecologics and Ergonomics – complying to the latest standards including TCO 6.0 and ISO 6-0.
- Cost Saving Device Management – save effort whilst managing all connected NEC devices from a centralised location by using the NaViSet Administrator 2 software tool.
Technical details
ECO mode
Yes
On/Off timer
Yes
Panel type
IPS
Display
Display brightness (typical)
250 cd/m²
Display diagonal
23 "
Display technology
LED
Display resolution
1920 x 1080 pixels
HD type
Full HD
Response time
6.00 ms
Contrast ratio (typical)
1000:1
Contrast ratio (dynamic)
25000:1
Viewing angle, horizontal
170.00 °
Viewing angle, vertical
160.00 °
Display number of colours
16.78 million colours
Screen shape
Flat
Pixel pitch
0.265 x 0.265 mm
Display diagonal (metric)
58.00 cm
Native aspect ratio
16:9
Supported graphics resolutions
640 x 480 (VGA),720 x 400,800 x 600 (SVGA),1024 x 768 (XGA),1152 x 864 (XGA+),1280 x 1024 (SXGA),1360 x 768 (WXGA),1400 x 1050 (SXGA+),1440 x 900 (WXGA+),1680 x 1050 (WSXGA+),1920 x 1080 (HD 1080)
Touchscreen
No
Aspect ratio
16:9
Audio
Built-in speaker(s)
Yes
RMS rated power
2.00 W
Ports & interfaces
Built-in USB hub
No
DVI-D ports quantity
1
DisplayPorts quantity
1
DVI ports
1
Total number of outputs
2
Displayport ports
1
Weight & dimensions
Width (without stand)
544.30 cm
Width
544.30 mm
Depth
53.30 mm
Height
322.20 mm
Width (with stand)
544.30 mm
Depth (with stand)
213.90 mm
Height (with stand)
374.50 mm
Depth (without stand)
53.30 cm
Height (without stand)
322.20 cm
Power
Power consumption (typical)
17.00 W
Annual energy consumption
25.00 kWh
AC input voltage
100 - 240 V
Energy efficiency class
A+
Power consumption (PowerSave)
0.35 W
Operational conditions
Operating temperature (T-T)
5 - 35 °C
Storage temperature (T-T)
20 - 80 °C
TV tuner
TV tuner integrated
No
Certificates
Energy Star certified
Yes
Certification
CE, ErP, FCC Class B, ISO 9241-307, Low Blue Light, PCT/Gost, TCO 6.0, TÜV Ergonomics, TÜV GS, UL/C-UL (CSA)
Ergonomics
Pivot angle
0 - 90 °
VESA mounting
Yes
Panel mounting interface
100 x 100 mm
Cable lock slot
Yes
Height adjustment
Yes
Height adjustment
110.00 cm
Pivot
Yes
Swivelling
Yes
Tilt adjustment
Yes
Tilt angle range
-5 - 20 °
Swivel angle range
-45 - 45 °
Plug and Play
Yes
Packaging content
Stand included
Yes
Cables included
AC,DVI,VGA
Quick start guide
Yes
Other features
DVI port
Yes
Design
Feet colour
White
Product colour
White
Cable lock slot type
Kensington
Bezel width (side)
16.40 cm
Bezel width (top)
16.80 cm
Bezel width (bottom)
16.80 cm
Display
LED
Performance
NVIDIA G-SYNC
No
AMD FreeSync
No
Horizontal scan range
31.5 - 81.1 kHz
Vertical scan range
56 - 76 Hz
Sustainability
European Product Registry for Energy Labelling (EPREL) code
391637
Features
3D
No
Thin Client
Thin client installed
No
Loudspeakers
Number of speakers
2.00
Multimedia
Built-in camera
No
Energy efficiency class (SDR)
C
Energy efficiency scale
A to G
Energy consumption (SDR) per 1000 hours
10 kWh
Maximum refresh rate
60.00 Hz
Weight (with stand)
5700 kg
Tiltable
Y
Sustainability certificates
ENERGY STAR
Harmonized System (HS) code
85285210
Energy efficiency class (old)
A+
