This product is no longer available.
One of the successors is Canon XEED WUX500
Canon XEED WX520
Item code
8265B003
EAN-code
4960999974064
Solutions
Projection
Projector brightness
5200 lumen
Downloads
Click here for the downloads
Are you interested in purchasing this product?
Related products
Highlighted functionality
Specifications
Compact, bright, energy efficient WXGA+ installation projector with lens shift.
Canon’s most compact WXGA+ installation projector. The brilliant 5200 lumens stays constant* across the zoom range.
- Native WXGA+ resolution
- 5200 lumens
- 2000:1 contrast
- 1.8x zoom lens with vertical and horizontal shift
- Picture-by-picture and edge blending
- HDMIâ„¢ and DVI inputs
- PC-less presentation
- Easy lamp and filter access
- Class-leading** energy efficiency
Canon’s most compact WXGA+ installation projector. The brilliant 5200 lumens stays constant* across the zoom range.
- Native WXGA+ resolution
- 5200 lumens
- 2000:1 contrast
- 1.8x zoom lens with vertical and horizontal shift
- Picture-by-picture and edge blending
- HDMIâ„¢ and DVI inputs
- PC-less presentation
- Easy lamp and filter access
- Class-leading** energy efficiency
Technical details
Bulb power
250.00 W
Placement
Desktop
HDCP
Yes
Display
Contrast ratio (typical)
2000:1
Native aspect ratio
16:10
Supported graphics resolutions
1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 768 (WXGA),1280 x 800 (WXGA),1360 x 768 (WXGA),1400 x 1050 (SXGA+),1440 x 900 (WXGA+),1600 x 1200 (UXGA),1680 x 1050 (WSXGA+),640 x 480 (VGA),800 x 600 (SVGA)
Audio
Number of built-in speakers
1.00
Built-in speaker(s)
Yes
RMS rated power
5.00 W
Ports & interfaces
HDMI ports quantity
1
Composite video in
0
Component video (YPbPr/YCbCr) in
0
Audio (L/R) in
2.00
VGA (D-Sub) ports quantity
1
RS-232 ports
0.00
Audio (L/R) out
1.00
Ethernet LAN (RJ-45) ports
1.00
S-Video inputs quantity
0
USB 2.0 ports quantity
1.00
VGA ports
1
Total number of outputs
1
HDMI ports
1
DVI ports
1
Weight & dimensions
Width
337.00 mm
Depth
370.00 mm
Height
134.00 mm
Weight
5900.00 g
Power
Power consumption (typical)
355.00 W
Power consumption (standby)
0.60 W
AC adapter frequency
50/60 Hz
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power source
AC
AC adapter input voltage
100 - 240 V
Power consumption (PowerSave)
285.00 W
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-10 - 60 °C
Network
Ethernet LAN
Yes
Ethernet LAN
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
Packaging content
Remote control included
No
Other features
Wi-Fi
No
DVI port
Yes
Screen size compatibility
40 - 300 "
Design
Product colour
Black, Silver
Built-in display
N
Performance
Noise level
38.00 dB
Noise level (economic mode)
32.00 dB
Digital zoom
12.00 x
Product type
Standard throw projector
Storage
Card reader integrated
No
Features
3D
No
Fridge
Lamp type
NSHA
Video
Full HD
No
Supported video modes
1080i,1080p,480i,480p,576i,576p,720p
Lens system
Vertical lens shift range
0 - 62 %
Magnification
1.80 x
Throw ratio
1.43 - 2.57:1
Projection distance
1.2 - 16.6 m
Focal length range
21.7 - 39 mm
Minimum projection distance
1.2 m
Maximum projection distance
16.6 m
Projector
Projector brightness
5200 lumen
Projection technology
LCOS
Projector native resolution
WXGA+ (1440x900)
Supported aspect ratios
16:10
Uniformity
90.00 %
Keystone correction, horizontal
-20 - 20 °
Keystone correction, vertical
-20 - 20 °
Matrix size
0.70 cm
Matrix type
3-panel (p-Si TFT active)
Lamps
Light source type
Lamp
Lamp power
250 W
