This product is no longer available.

NEC U321Hi Interactive Multitouch P

Item code 60003945
EAN-code 5028695611771
Solutions Projection
Projector brightness 3200 lumen

Are you interested in purchasing this product?

Related products
Highlighted functionality
Specifications
This ultra-short throw interactive projector releases space within small to medium sized classrooms and meeting rooms, projecting onto screen sizes between 85-100” without creating shadow or glare, allowing users to get up close in comfort to interact using the Multi-Touch function.

With 1080p resolution and 10.000:1 contrast, the U321Hi Multi-Touch delivers perfect image quality for very detailed content as well as high quality movies including 3D content from Blu-Ray players, thanks to HDMI 3D support. Demanding applications in higher education such as design and engineering will appreciate the 1080p resolution for the high level of detail achieved.
BENEFITS

- Great picture quality - thanks to 1080p resolution and 10000:1 contrast.
- Almost no shadow and glare - thanks to ultra-short throwing distance.
- Future proof connectivity - due to numerous analog and digital connection terminals including MHL support, network capability as well as optional wireless connectivity.
- Wall-mount included - for quick and easy installation, compatible with height adjustable systems.
- Cost effective replacement - of existing NEC UM Series installations to achieve higher resolutions without re-positioning of the existing wall-mount.
- Multi-Touch Interactivity - 255 touch points and auto-calibration.
- 3D ready - for playback of engaging 3D applications and movies.
- Free DisplayNote Multiuser Licence - present, share, collaborate with up to 5 participants across multiple devices (available until March 2016).
- Special Characteristics - AMX Beacon; Auto Eco Mode; Auto Power ON/OFF; Crestron RoomView; DICOM Simulation; Direct Power-Off Function; High Altitude Mode; Kensington security slot; Keypad Lock; Manual vertical Keystone Correction (V= ±5°); Magnify; NaViSet Administrator 2; OSD with 30 languages; Off-Timer; Optional User Logo; PJ LINK; Password Security System; Quick On/Off; Remote control and administration via LAN and RS232; Security Bar; Test Pattern; Wall Colour Correction

Technical details

Bulb power
260.00 W
Placement
Desktop
Remote control type
IR
Service life of lamp
3000.00 h
Lamps quantity
1.00

Display

Contrast ratio (typical)
10000:1
Native aspect ratio
16:9
Supported graphics resolutions
640 x 480 (VGA),720 x 480,720 x 576,800 x 600 (SVGA),832 x 624,1024 x 768 (XGA),1152 x 864 (XGA+),1152 x 870,1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 768 (WXGA),1280 x 800 (WXGA),1280 x 960,1360 x 768 (WXGA),1366 x 768,1400 x 1050 (SXGA+),1440 x 900,1600 x 1200 (UXGA),1600 x 900,1920 x 1080 (HD 1080)

Audio

Number of built-in speakers
1.00
Built-in speaker(s)
Yes
RMS rated power
8.00 W

Ports & interfaces

HDMI connector type
Full-size
HDMI ports quantity
2
Audio (L/R) in
1.00
AUX in
Yes
VGA (D-Sub) ports quantity
2
RS-232 ports
1.00
Ethernet LAN (RJ-45) ports
1.00
USB connector type
Mini-USB,USB Type-A
Serial interface type
RS-232
AC (power) in
Yes
PC in (D-Sub)
Yes
USB 2.0 ports quantity
2.00
Headphone outputs
1.00
Microphone in
Yes
VGA ports
2
Total number of outputs
2
HDMI ports
2
DVI ports
0

Weight & dimensions

Width
383.00 mm
Depth
308.00 mm
Height
85.00 mm
Weight
4700.00 g

Power

Power consumption (typical)
312.00 W
Power consumption (standby)
0.30 W
AC adapter frequency
50/60 Hz
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power source
AC
AC adapter input voltage
100 - 240 V
Power consumption (economy mode)
264.00 W

Operational conditions

Operating temperature (T-T)
5 - 40 °C
Operating relative humidity (H-H)
20 - 80 %
Storage temperature (T-T)
-20 - 60 °C
Storage relative humidity (H-H)
20 - 90 %

Network

Ethernet LAN
Yes
Ethernet LAN
Yes

Certificates

RoHS compliance
Yes
Certification
CE; Gost-R; TÜV GS

Management features

On Screen Display (OSD)
Yes

Ergonomics

Cable lock slot
Yes

Packaging content

Remote control included
Yes
Mounting brackets included
Yes
Cables included
AC,VGA
Manual
Yes
Quick start guide
Yes

Other features

Wi-Fi
No
DVI port
No
Screen size compatibility
85 - 100 "

Design

Product colour
White
Built-in display
N
Cable lock slot type
Kensington

Performance

Password protection
Yes
Noise level
34.00 dB
Noise level (economic mode)
29.00 dB
Zoom capability
Yes
Analog signal format system
NTSC,NTSC 3.58,NTSC 4.43,PAL,PAL 60,PAL M,PAL N,SECAM
Vertical scan range
50 - 120 Hz
Horizontal scan range
15 - 100 kHz
Product type
Ultra short throw projector

Storage

Card reader integrated
No

Video

3D Ready
Yes
Full HD
Yes
Supported video modes
480i,480p,576i,576p,720p,1080i,1080p

Lens system

Focus
Manual
Fixed focal length
3.72 mm
Aperture range (F-F)
2.4 - 2.4
Zoom type
Manual
Offset
65.00 %
Throw ratio
0.25:1
Projection distance
0.195 - 0.306 m
Minimum projection distance
0.195 m
Maximum projection distance
0.306 m

Projector

Projector brightness
3200 lumen
Projection technology
DLP
Projector native resolution
1080p (1920x1080)
Supported aspect ratios
16:9
Keystone correction, vertical
-5 - 5 °

Lamps

Service life of light source
3000 h
Light source type
Lamp
Lamp power
260 W
Lamp power (economic mode)
220.00 W
Service life of lamp (economic mode)
4000.00 h

Light source

Service life of light source (economic mode)
4000 h

Sustainability certificates
RoHS
Compliance certificates
RoHS
