This product is no longer available.
NEC PX750UG2
Item code
60003829
EAN-code
5028695610934
Solutions
Projection
Projector brightness
7500 lumen
Downloads
Click here for the downloads
Are you interested in purchasing this product?
Related products
Highlighted functionality
Specifications
The PX750U is the ideal projector for installations that demand the highest levels of heavy duty usage, unique picture quality in highest resolution and is the worldwide first projector supporting STv2, compatible with the NEC /Intel OPS standard.
The professional features make it ideal for Rental/Staging, Large Corporate, High Education, Conference Room, Museum and Signage.
BENEFITS
- Display content that demands attention - with Full-HD resolution and superb brightness levels and colour ranges, your viewers will enjoy an outstanding visual experience.
- Installation is easy, even in challenging venues - a motorized Lens Shift with vertical and horizontal adjustment makes setting up the perfect installation image easy.
- Simple Connectivity - due to the vast number of connectors featured with this projector, including an innovative DisplayPort terminal and a host of networking, analog and digital connection terminals.
- Time saving network control - for cost saving convenient maintenance and management of content and scheduling.
- Cost Saving Device Management - save effort whilst administrating all connected NEC devices from a centralised location by using the NaViSet Administrator 2 software tool.
- Special Characteristics - Digital 3D Reform™; 3D Stacking; AMX Beacon; Blanking; 2x Colourwheel; Crestron RoomView; Direct Power-Off Function; Edge Blending Function; Geometric Correction; Help Function; Keystone Correction (H=±35°, V=±30°); LAN control; Lens Memory; Lens Shift (vertical 0.5, horizontal ± 0.1); Lens Shutter; NaViSet Administrator 2Ajax Loading Icon; OSD with 27 languages; Optional User Logo; Outstanding Multimedia and Network Functions; PIP/Side by Side, HDMI - Input; PJ LINK; Password Security System; Plug&Play W-LAN Option; Powerpoint, Movie, PDF and USB Picture Viewer; RS-232 Control; SNMP; Seamless Switching; Stacking Function; Test Pattern; Windows 7 Network Projector; Complete shut-off switch; Intelligent Power Management
The professional features make it ideal for Rental/Staging, Large Corporate, High Education, Conference Room, Museum and Signage.
BENEFITS
- Display content that demands attention - with Full-HD resolution and superb brightness levels and colour ranges, your viewers will enjoy an outstanding visual experience.
- Installation is easy, even in challenging venues - a motorized Lens Shift with vertical and horizontal adjustment makes setting up the perfect installation image easy.
- Simple Connectivity - due to the vast number of connectors featured with this projector, including an innovative DisplayPort terminal and a host of networking, analog and digital connection terminals.
- Time saving network control - for cost saving convenient maintenance and management of content and scheduling.
- Cost Saving Device Management - save effort whilst administrating all connected NEC devices from a centralised location by using the NaViSet Administrator 2 software tool.
- Special Characteristics - Digital 3D Reform™; 3D Stacking; AMX Beacon; Blanking; 2x Colourwheel; Crestron RoomView; Direct Power-Off Function; Edge Blending Function; Geometric Correction; Help Function; Keystone Correction (H=±35°, V=±30°); LAN control; Lens Memory; Lens Shift (vertical 0.5, horizontal ± 0.1); Lens Shutter; NaViSet Administrator 2Ajax Loading Icon; OSD with 27 languages; Optional User Logo; Outstanding Multimedia and Network Functions; PIP/Side by Side, HDMI - Input; PJ LINK; Password Security System; Plug&Play W-LAN Option; Powerpoint, Movie, PDF and USB Picture Viewer; RS-232 Control; SNMP; Seamless Switching; Stacking Function; Test Pattern; Windows 7 Network Projector; Complete shut-off switch; Intelligent Power Management
Technical details
Bulb power
400.00 W
Placement
Desktop, Ceiling
Image formats supported
JPG
Remote control type
IR
Service life of lamp
2000.00 h
Lamps quantity
2.00
HDCP
Yes
Display
Contrast ratio (typical)
2100:1
Native aspect ratio
16:10
Supported graphics resolutions
1920 x 1200 (WUXGA),640 x 480 (VGA)
Ports & interfaces
HDMI ports quantity
1
HDMI version
1.3
VGA (D-Sub) ports quantity
3
RS-232 ports
1.00
Ethernet LAN (RJ-45) ports
1.00
USB connector type
USB Type-A
Serial interface type
RS-232
S-Video inputs quantity
1
BNC input ports
5.00
PC in (D-Sub)
Yes
USB 2.0 ports quantity
2.00
DisplayPorts quantity
1
VGA ports
3
Total number of outputs
2
HDMI ports
1
Displayport ports
1
S-Video ports
1
DVI ports
0
Weight & dimensions
Width
504.00 mm
Depth
516.00 mm
Height
192.00 mm
Weight
19700.00 g
Power
Power consumption (network standby)
23 W
Power consumption (typical)
958.00 W
Power consumption (standby)
0.40 W
AC adapter frequency
50/60 Hz
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power source
AC
AC adapter input voltage
100 - 240 V
Power consumption (economy mode)
515.00 W
Network
Ethernet LAN
Yes
Ethernet LAN
Yes
Certificates
RoHS compliance
Yes
Certification
CE; ErP; TÃœV GS
Management features
On Screen Display (OSD)
Yes
Packaging content
Remote control included
Yes
Mounting brackets included
Yes
Cables included
AC
Manual
Yes
Quick start guide
Yes
Other features
Wi-Fi
No
DVI port
No
Screen size compatibility
50 - 500 "
Design
Ceiling mountable
Yes
Product colour
Black
Built-in display
N
Performance
Preset modes
Cinema, Presentation
Password protection
Yes
Noise level
40.00 dB
Zoom capability
Yes
Vertical scan range
48 - 120 Hz
Horizontal scan range
15 - 108 kHz
Product type
Large venue projector
Storage
Card reader integrated
No
Features
3D
No
Video
Full HD
Yes
HD-Ready
Yes
Supported video modes
1080i,1080p,480i,576i,576p,720p
Software
Windows operating systems supported
Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64
Lens system
Focus
Auto
Zoom type
Auto
Horizontal lens shift range
-0.1 - 0.1 %
Vertical lens shift range
0.5 - 0.5 %
Number of optional lenses supported
7
Projection distance
0.9 - 20.8 m
Minimum projection distance
0.9 m
Maximum projection distance
20.8 m
Projector
Projector brightness
7500 lumen
Projection technology
DLP
Projector native resolution
WUXGA (1920x1200)
Supported aspect ratios
16:9,16:10
Keystone correction, horizontal
-35 - 35 °
Keystone correction, vertical
-30 - 30 °
Matrix size
0.70 cm
Maximum digital resolution
1920 x 1200 pixels
Lamps
Service life of light source
2000 h
Light source type
Lamp
Lamp power
400 W
Lamp power (economic mode)
320.00 W
Service life of lamp (economic mode)
2500.00 h
Light source
Service life of light source (economic mode)
2500 h
Sustainability certificates
RoHS
Compliance certificates
RoHS
